Commodore Wall Mount Boiler

Our latest product innovation, the Ideal match for commercial needs. Easy to install featuring low weight and compact size. The Commodore Wall Mount Boiler comes loaded with features such as: a robust stainless steel heat exchanger, modulation up to 6.5:1, modbus connection as standard and easy-to-read error history. Sizes are available in 299, 399, 470 and 500 MBH.

Warranty WARRANTY

The Ideal Advantage Industry Leading Warranty Program | Standard – 2-year parts and 10-year primary heat exchanger warranty. | Plus – 5-year parts, 2-year labor allowance, and 10-year primary heat exchanger warranty with registration. | Elite – 6-year parts, 3-years labor and 12-year heat exchanger warranty offered with registration, combustion analysis and hydronic system treatment.

  • Best Warranty
  • Best Warranty
  • Best Warranty
DETAILS

  • Optional BACnet Accessory

  • Models Range From 299 To 500 MBH

  • Cascade Up To 16 Boilers

  • Easy-To-Read Error History

  • Modulation Up To 6.5:1

  • Modbus Connection As Standard

  • Field Convertible

Videos

Model Comparison Model Comparison

Commodore WM299399470500

  • Model Number
  • CB299W
  • CB399W
  • CB470W
  • CB500W

Performance Specs

  • Input MBH Min.
  • 46
  • 72
  • 83
  • 83
  • Input MBH Max
  • 299
  • 399
  • 470
  • 500
  • Output MBH *
  • 289
  • 381
  • 453
  • 475
  • Net AHRI Rating MBH
  • 238
  • 329
  • 394
  • 413
  • AFUE **
  • 95.1%
  • -
  • -
  • -
  • Thermal Efficiency **
  • -
  • 95.5%
  • 95.6%
  • 95.1%
  • Combustion Efficiency **
  • -
  • 95.4%
  • 95.1%
  • 94.5%

Technical Data

  • Turn Down
  • 6.5:1
  • 5.5:1
  • 5.7:1
  • 6:1
  • Rated Volume
  • 2.1
  • 2.5
  • 2.7
  • 2.7
  • S/R Water Conn. MNPT
  • 1-12"
  • 1-1/2"
  • 1-1/2"
  • 1-1/2"
  • Gas Conn. NPT
  • 1"
  • 1"
  • 1"
  • 1"
  • Flue Conn. Vent/Air
  • 4"
  • 4"
  • 6"
  • 6"
  • Vent Length
  • 200'
  • 121'
  • 200'
  • 200'
  • Dimensions (W / H / D)
  • 17-1/2" x 33-1/3" x 21-1/5"
  • 17-1/2" x 33-1/3" x 21-1/5"
  • 17-1/2" x 33-1/3" x 21-1/5"
  • 17-1/2" x 33-1/3" x 21-1/5"
  • Weight (lbs.)
  • 184
  • 193
  • 198
  • 198

* Output is "Heating Capacity" for units with inputs <300 MBH and "Gross Output" for units > 300 MBH.

Documents Documents

Product / Marketing Literature

Installation / User Manuls

Specifications

Submittals

Commissioning

Commodore Wall Boiler

HOW TO GET ONE

Find a Distributor
